The most advanced R1234yf unit on the market today, the ArcticPRO ACX2280 refrigerant handling system offers your shop the ultimate in high-end refrigerant recycling machines.







  • State-of-the-art, ergonomic design, 7" capacitive touch screen and intuitive user interface sets a new industry standard.
  • New ergonomic hinged service door simplifies unit service.
  • LED light indicates status visible from anywhere in the workshop.
  • iOS and Android capable phone app allows remote service session mirroring and advanced functions.
  • Permanent, automatic wireless software updates, ensuring you always have the latest features.
  • Oil management system automatically weighs recovered oil, allowing accurate replenishment of oil removed during service.
  • Offers remote support capabilities that allow MAHLE technicians to connect to a unit over WiFi for troubleshooting and advanced support.
  • Data management and reporting capabilities provide the ability to log and monitor services allowing analytics for proactive service reminders, refrigerant use optimization, warranty reporting and more.
  • An integrated refrigerant identifier adds additional convenience and saves time on services.
  • Every unit is built to be easily repaired by the owner and we proudly offer nationwide service centers and lifetime phone support coverage.
  • The unit retains valuable service records, providing network printing capability to print services provided for customer.



  • Optional thermal printer allows printing of service reports.



Certifications SAE J2843, SAE J2888, UL 1963

Charge Performance +/- 0.5 oz. at 70° to 75°F (+/- 15g at 21° to 24°C)

Recovery Performance 95% at 70° to 75°F (21° to 24°C) within 30 minutes

Operation Fully Automatic

Charging Cylinder 30 lb. (13.6 kg) DOT

Compressor 3/8 HP-0.279kW

Dimensions (H x W x D) 47 in x 29 in x 29 in (119 cm x 74 cm x 74 cm)

Weight 215 lb. (98 kg)

Display Color, 7” Capacitive Touch Screen

Filter Drier Capacity 200 lb. (91 kg) spin-on type

Hoses 9 ft. (2.75 m)

Hybrid Function Certified

Languages English, French, Spanish

Operating Ranges 50 degrees - 122 degrees F (10° to 50°C)

Power Source 120 VAC - 60 HZ - 12 AMP

Vacuum Pump 2 CFM dual stage

Warranty 1 Year Labor, 2 Years Part




360 83254 00 Filter Combo

026 80785 00 Dust Cover

026 80698 00 Oil Charge Bottle

026 80699 00 Oil Drain Bottle

360 82948 00 Red Hose R1234YF

360 82949 00 Blue Hose R1234YF

360 82951 00 Quick Release Low Side Coupling R1234YF

360 82950 00 Quick Release High Side Coupling R1234YF

360 82744 00 Calibration Check Ball

360 82953 00 Adaptor LP (External Bottle) USACME 1/2 LH R1234YF

026 80635 00 LD-2 Leak Detector R1234YF

026 80700 00 Vacuum Pump VE215

011 80070 00 Vacuum Pump Oil (Quart)

360 83269 00 Thermal Printer Installation Kit

360 83110 00 Thermal Printer Paper 5PK


Mahle ACX2280 R1234yf Refrigerant Handling System
